DCM BURNER This is one kind of design installed in the
combustion chamber specially, and is special-purpose
burner to make hot air.
●Combustion
Capacity: 100,000~600,000 (Kcal/Hr)
●Shape
of Flame: Radiated
●Working
Temp.: 400℃ reachable, unable acid-proof
●Applications: •Baking oven
•Drying
oven
•Heating
furnace
•Other
heat-treatment furnace
|
-----------------------------------------------------------------------------------------------------------------------------------------
 |
BJ BURNER This is one kind of design adopted single assembly and
is GUN-TYPE Burner with great combustion capacity.
●Combustion
Capacity: 400,000~1,000,000 (Kcal/Hr)
●Shape
of Flame: Radiated
●Working
Temp.: 400℃ reachable, unable acid-proof
●Applications: •Baking oven
•Drying
oven
•Heating
furnace
•Other
heat-treatment furnace
|
----------------------------------------------------------------------------------------------------------------------------------------
 |
SBII BURNER This is one kind of Burner design
for low noise.
●Combustion
Capacity: 150,000~350,000 (Kcal/Hr)
●Shape
of Flame: Radiated
●Working
Temp.: 400℃ reachable, unable acid-proof
●Applications: •Baking oven
•Drying
oven
•Heating
furnace
•Other
heat-treatment furnace
|
---------------------------------------------------------------------------------------------------------------------------------------
 |
SIM BURNER This is one kind of immersion burner developed
for heating in a liquid tank.
●Combustion
Capacity: 100,000~200,000 (Kcal/Hr)
●Shape
of Flame: Laminar, long flame
●Working
Temp.: 400℃ reachable, Slightly acid-proof and
dust-proof
●Applications: •Heating of liquid tank |
---------------------------------------------------------------------------------------------------------------------------------------
 |
AH
BURNER This is a special-purpose burner to
make heat air, and is an extremely durable and energy-saving
(combustion efficiency may reach 99%) burner.
●Combustion
Capacity: 200,000~1,600,000 (Kcal/Hr)
●Shape
of Flame: Centralized type, line shape
●Working
Temp.: 400℃ reachable, special order for acid-proof
●Applications: •Baking oven
•Drying
oven
•Heating
furnace
•Other
heat-treatment furnace |
---------------------------------------------------------------------------------------------------------------------------------------
 |
RTE
BURNER This is one kind of burner developed specially for radiation
tubes.
●Combustion
Capacity: 35,000~125,000 (Kcal/Hr)
●Shape
of Flame: Laminar, long flame
●Working
Temp.: 900℃ reachable
●Applications: •High temperature oven
•Indirect
air heater
•Annealing
furnace
•Cementation
quenching oven
•Quenching
furnace
•Reverberatory |
---------------------------------------------------------------------------------------------------------------------------------------
 |
TRF BURNER is single end type and main body has
heat exchange inside. It is a compact energy-saving
burner.
●Combustion
Capacity: 35,000~125,000 (Kcal/Hr)
●Shape
of Flame: Laminar, long flame
●Working
Temp.: 900℃ reachable
●Applications:•High temperature oven
•Indirect air heater
•Annealing furnace
•Cementation quenching oven
•Quenching furnace
•Reverberatory
|
---------------------------------------------------------------------------------------------------------------------------------------
 |
EIS
BURNER is nozzle mix type burner. It has a
wide combustion range. Especially, it has stable combustion
even if excessive air and it is able to use for an industrial
furnace widely.
●Combustion Capacity: 50,000~600,000 (Kcal/Hr)
●Shape of Flame: Straight-moving flame, combustion speed can reach 60m/s
●Working Temp.: 1400℃ reachable
●Applications•Heating furnace
•Heat treatment furnace
•Hardening furnace
•Revolving furnace
•Reverberatory
•Hot air generator
•Furnace for melting glasses |
---------------------------------------------------------------------------------------------------------------------------------------
 |
EIL BURNER
●Combustion Capacity: 100,000~800,000 (Kcal/Hr)
●Shape of Flame: Reducible flame
●Working Temp.: 1200℃ reachable
●Applications:•Furnace for melting aluminum
|
---------------------------------------------------------------------------------------------------------------------------------------
 |
SH BURNER Infrared-ray gas burner releases heat by radiation through fuel gas.
●Combustion Capacity: 2,030~9,360 (Kcal/Hr)
●Shape of Flame: Infrared-ray
●Working Temp.: 250℃ reachable
●Applications:•Restaurant
•Painting Industry
•Farm *Food Industry
•Fiber Industry
•Plastic gloves
•Ceramic Industry
•Paper Industry |
--------------------------------------------------------------------------------------------------------------------------------------
 |
BS BURNER *High radiant efficiency, energy-saving *Light and simple installation *Free heating direction *Stabile combustion *safe Self-ignition/combustion device
●Combustion Capacity: 5,000~30,000 (Kcal/Hr)
(Special Combustion capacity could be made.)
● Shape of Flame: Infrared-ray
●Working Temp.: 250℃ reachable
●Applications:•Painting Industry
•Food Industry *
•Fiber Industry
•Plastic gloves
•Ceramic Industry
•Paper Industry |
---------------------------------------------------------------------------------------------------------------------------------------
 |
RIBBON BURNER is the most suitable to be the burner for line-oven. It has even-spread and stable combustion.
●Combustion Capacity: 35,000~125,000 (Kcal/Hr)
●Shape of Flame: short flame parallel shape
●Working Temp.: 900℃ reachable
●Applications:•Line oven
•Food roaster |
---------------------------------------------------------------------------------------------------------------------------------------
 |
EHW infrared-ray plate Because Far-infrared ray reaches
interior of objects(several mm) to heats up evenly,therefore even if it does not make direct heating on the surface of material, also gets great effect. For
example: In the case of paint-drying, it also could get great interior hardness of coating without bubbles.
●Heating way: Far infrared-ray
●Working Temp.: 300℃ reachable
●Applications:•Coating oven
•Drying furnace
•Other indirect –heating furnace |
---------------------------------------------------------------------------------------------------------------------------------------
Suitable fuel: Each kind of gas like Town gas, Natural gas,Butane gas… and so on. |
